Smart DPS G 700w Bronze Smart DPS G 700w Bronze Smart DPS G 700w Bronze Smart DPS G 700w Bronze Smart DPS G 700w Bronze Smart DPS G 700w Bronze
Smart DPS G 700w Bronze

Smart DPS G 700w Bronze

Out of stock
P/N
PS-SPG-0700DPCBUS-B
USD$99.99

Smart Series SPG-0700D-B – 700W 80 PLUS® Bronze Certified Semi-Modular APFC PSU


SMART DPS G 700W Bronze

The Thermaltake SMART DPS G Bronze Series are digital power supply units (PSU) that incorporate various high-tech components, leading technology and Eco-friendly commendations, featuring 80 PLUS Bronze certification with a semi-modular that always accommodate any mainstream build under any circumstance.

The combination of Smart DPS G Bronze and three intelligent platforms – DPS G PC APP 3.0, DPS G Smart Power Management (SPM) Cloud 1.0, and DPS G Mobile APP 1.0 helps users not just monitor smart power supply units, but also save the energy, reduce CO2 emission, and eventually protect the Earth.

What is Smart Power Management (SPM)?

Smart Power Management (SPM) is a cloud-based software that seamlessly integrates three intelligent platforms – DPS G PC APP 3.0, DPS G Smart Power Management Cloud 1.0 and DPS G Mobile APP 1.0 – and compiles key statistics about your PC into detailed charts and breakdowns for your instant PC status view and management. With easy access to SPM through your PC or mobile devices, whether you are outside or indoors, enjoy taking full control of your build anytime, anywhere!

Warning Alert

The SPM platform comes with real-time warning alert function, which will appear on your DPS G Mobile APP/DPS G Smart Power Management Cloud and also your email when fan failure, PSU over temperature (over 140℉/60℃), or abnormal voltage level (over/under 5% of normal level) occurs. Then users can shut down their PC remotely to avoid further damage.

Schedule Shutdown

Save PC energy and electricity cost by scheduling your PC to shutdown at any time you want through DPS G Mobile APP or DPS G Smart Power Management Cloud.

High Quality Japanese Main Capacitors

The Smart DPS G Bronze Series features Japanese main capacitors, which greatly improves the durability and offers the highest stability and reliability. No more capacitor explosion and leakage.

Flat Modular Cables

Smart DPS G Bronze Series is semi-modular power supply that offers cable selection for users while powering the system at an advantageous voltage. All new low-profile flat modular cables enhance the airflow as well as improve the thermal performance of the chassis. Moreover, flat cables are softer which make cable routing easier to install.

Core Component: MCU

Smart DPS G Series comes with a 32Bit Microcontroller Unit (MCU) from Microchip Technology. The 32Bit Microcontroller Unit is a small computer on a single integrated circuit containing a processor core, memory, and programmable input/output peripherals. MCU can digitally control devices and processes, such as automobile engine control systems and office machines.

High Current Single +12V Rail

Smart DPS G Bronze Series is equipped with a powerful single +12V rail, please see the output specification below:

AC INPUT

Input Voltage: 100V - 240V
Input Current: 10A
Frequency: 47Hz - 63Hz

DC OUTPUT +3.3V +5V +12V -12V +5Vsb
Max Output Current 22A

18A

54A

0.3A

2.5A
Max Output Power

130W

648W

3.6W

12.5W

Continuous Power

700W

80 PLUS Bronze-certified and Kaby Lake-Ready

Smart DPS G Power Supply with DPS G software delivers up to 86% efficiency under real-world load conditions, promising the lowest power losses. Additionally, Smart DPS G Bronze Series has been optimized to work with Intel’s new, Seventh-generation Kaby Lake processors to achieve maximum energy savings.

TT RGB PLUS Software

2.0 - New version of Thermaltake’s TT RGB PLUS patented software, providing more lighting effects and PC monitoring functions.
1.0 - Thermaltake’s patented software to synchronize TT RGB PLUS products with addressable LEDs.
Caution: TT RGB PLUS 2.0 and TT RGB PLUS 1.0 will overwrite one another; users can only install one version of TT RGB PLUS.

2.0 DOWNLOAD NOW 2.0 USER MANUAL
1.0 DOWNLOAD NOW LEARN MORE

TT RGB PLUS Logo
More Information
P/N PS-SPG-0700DPCBUS-B
watts 700W
RGB Fan No
Form Factor ATX
Model SPG-700DH2CCB
Type Intel ATX 12V 2.31 & SSI EPS 12V 2.92
Max. Output Capacity 700W
Peak Output Capacity 840W
Color Black
Dimension ( W / H / D ) 150mm(W) x 86mm(H) x 140mm(D)
PFC (Power Factor Correction) Active PFC
Power Good Signal 100-500 msec
Hold Up Time > 10msec at 80% of full load (230Vac input)
Input Current 10A
Input Frequency Range 47Hz - 63Hz
Input Voltage 100V - 240V
Operating Temperature 0 ℃ to +40℃
Operating Humidity 20% to 90%,non-condensing
Storage Temperature

-20 ℃ to +70 ℃

Storage Humidity 5% to 95%, non-condensing
Cooling System 12cm dual ball bearing Fan
Efficiency MEET 80 Plus Bronze at 115Vac input.
MTBF 120,000 hrs minimum
Safety Approval CE/FCC/UL/TUV/CB/EAC/BSMI
PCI-E 6+2pin PCI-E 6+2pin X 4
Protection OPP, OVP, UVP,OTP

User Manual

  • File Name
  • Description
  • Size
  • Version
  • Release Date

Drivers & Software

  • File Name
  • Description
  • Size
  • Version
  • Release Date
  • DPS G App
  • 1.Made minor bug fixes and system performance improvements.
  • V3.3.3
  • 2024-03-19
